Serge '73 VCF ,original layout from Serge ,using 2 x CA3080 , i cleaned up this layout to my taste and build this filter using this ..twice ,little tip : if you're using this layout and don't have a metal can CA3080 you can use that chip in SMD with adapter ,using CA3080 in TH can be hard ,this one and few other original layouts from that Serge system can still be found at the wayback machine . Here is Gerber files for this interesting filter , you can see i did not completed the silkscreen since the original documentation contained that information .

This information was already online ,contact me if i need to remove it from this google website .

preslusaj i promotaj i skrati

 This is recorded with a homemade mixer and few homemade ring modulators

https://vladoshribski.bandcamp.com/album/loud

Homemade Serge

Simple pattern on my big serge-a-like modular ,few years ago ,before i sold it to pieces ,here using 2 x VCS ,a VC ADSR ,SSG and 73 VCF by Serge



Bandpass Gyrator Filters or almost an Octave filter



Bandpass Gyrator Filters or almost an Octave filter as presented by helge-h here at electro-music forum

i made 4 of these filters as part of my Matrix Mixer ,too bad that more then 6 position switches are really expensive ,but that is the only extra thing you need to expand this filter , i installed the capacitors on the switches as that makes sense to me

Orban 674



I started obsessing with this EQ when i found the schematics . Really something to DIY .This is a Gyrator based Para-Graphic EQ by Orban ,Good thing 4 pin potentiometers are still available until they are .Too bad i'm not as enthusiastic about building more gear ,this is deff something i'd try to make. Make as in Make-donija .

'96

 I have a suitcase full of bones from a highschooler that badly wanted a sampler . and a day comes once and again that i take the suitcase from under the bed ,take the bones out and drum as if i wanna bring him back to life ,or tell my fortune .Like someone the other day did cut down half a forest to build half a room .



This summary is not available. Please click here to view the post.

.



.



Lexicon LXP15



Lexicon LXP15 V2 for Sale

I don't use it enough to keep it and i'm trying to save money for some kind of Sampler/Groovebox.

I replaced the caps on it's PSU ,and replaced the rotary encoder that usually breaks with these machines . Can ship worldwide with UPS ,Payment with Pay Pal , Price for the machine is 150EU + shipping.

Contact : vladribarski@gmail.com

SynthesizerUnderConstruction

 Here are links to my other blog . These are all tested working layouts . If you can buy the kit ,it's easier but if you have a few spare parts and need a specific project maybe it's here : SynthesizerSecrets

SIAM (Siemens Inspired Equalizer )

Preamp and Envelope Follower ( By Juan Bermudes Costa)

Thomas Henry 555 VCO (Slim Version)

Crossfade Panner (Buchla Based)

Experimental Hardware Neurons (By Grant Richter)

Non-Linear Circuits Primal Hyperchaos

Non-Linear Circuits Jerk

Non-Linear Circuits SPasm

NLC Neuron/Grant Richter's CV Twister

CGS95 Reverb

Serge n-Step Programmer/Sequencer

Buchla Low Pass Gate/Envelope Follower

Serge Wavemultiplier/Overdrive

Paparail's VC AUX

Hagiwo's Addive VCO

Serge SSG/Bazier CUrve

Serge Triple Glide

Buchla 194

Yamaha GX BPF

Matrix Mixer



Matrix Mixer with gyrators as presented at electro-music forum ,this matrix mixer is with a twist ..each of the four stages has one input set to go thru the bandpass filter with rotation switches dedicated for purpose of filters set in the left side ,the upper and lower filter have two settings for resonance selectable via switch ,the 2nd and 3rd stage's 2nd and 3rd input have an attenuator switch ,as well as the 4th channel ,there was not enough space but in retrospect i'd add switchable boost on each channel in a form of additional 10 or 15K resistor at the output opamp ,the gyrator filters as expected make nice sinusoidal tones in feedback .This is really an active matrix mixer from CGS schematic ,each row can be set to unipolar or bipolar mixing and can be used for audio or cv mixing .

----- NOW THIS MATRIX MIXER IS NO LONGER FOR SALE -----

This unique Matrix Mixer with 4 Filters is for sale for 150EU + Shipping ,it works on +/-15V or +/-12V, i can include external PSU if you don't have one already but that might increase shipping costs , can ship worldwide with UPS ,payment with Pay Pal ,contact me for more info on vladribarski@gmail.com

......ooOOOOOOOooo



Gyrator Bandpass Filters
